Search antenna (20 MHz -200 MHz)
Search antenna (20 MHz-200 MHz), made in the form of two aluminum forms in plastic frame with the handle for carrying out searching. For its small dimensions, it has good characteristics for the lower range of frequency with the long wavelength.
- Specifications
| Frequency range |
20 MHz-200 MHz |
|
Shock-wave drag |
50 ohm |
|
Directional diagram |
forward |
|
Gain ration: |
|
|
on a frequency of 20 MHz |
-22 dB |
|
on a frequency of 50 MHz |
-19 dB |
|
on a frequency of 100 MHz |
-10 dB |
|
on a frequency of 200 MHz |
-2 dB |
|
Standing-wave ratio |
No more 1.5 |
|
Connector type |
SMA |
|
Dimensions |
380*280*90 mm |
Antenna directional pattern in the horizontal plane at a frequency of 100 MHz:
